UNV 4MP IP67 PoE NDAA Audio IP Network Uniview Security Camera
UNV 4MP IP67 PoE NDAA Audio IP Network Uniview Security Camera
SKU:IPC2324SR5-ADZK-G
Regular price
$439.00 USD
Regular price
Sale price
$439.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
UNV 4MP HD PoE Bullet NDAA Audio IP Uniview Security Camera with a 2.8-12mm Zoom Lens
The Uniview Camera with WDR technology enables clear image in strong light scene.
Key Features:
Megapixel: 4MP
Camera Style: Bullet
Compression : Ultra 265, H.265, H.264, MJPEG
Lens Type :motorized zoom lens
Lens Size : 2.8~12mm
Protection Code : IP67
Dimensions :206 × 74 × 74mm
Weight: 0.55kg (1.2lb)
Environmental : outdoor
Audio Support : Built-in Mic
-
Description:
The Uniview Bullet IP Camera stands as a testament to innovation and security. The Uniview is more than just a camera it's a guardian of your security. One of the standout features of the Uniview is its ability to capture crystal clear images and videos in high resolution. The Uniview Bullet IP Camera isn't just a security camera it's a game changer. The Uniview Camera Monitor an indoor or outdoor area with the . A built-in microphone enables this camera to pick up audio. An onboard card slot supports microSD cards up to 256GB with PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable.
Specification:
Camera |
||||||||||
| Sensor | 1/3", 4.0 megapixel, progressive scan, CMOS | |||||||||
| Lens | 2.8 ~ 12mm, AF automatic focusing and motorized zoom lens | |||||||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) | |||||
| 2.8 | 63.0 | 25.2 | 12.6 | 6.3 | ||||||
| 12 | 270.0 | 108.0 | 54.0 | 27.0 | ||||||
| Angle of View (H) | 102.79°~ 30.86° | |||||||||
| Angle of View (V) | 54.50°~ 17.49° | |||||||||
| Angle of View (O) | 106.94°~35.49° | |||||||||
| Adjustment angle | Pan: 0° ~ 360° | Tilt: 0° ~ 90° | Rotate: 0° ~ 360° | |||||||
| Shutter | Auto/Manual, 1 ~ 1/100000s | |||||||||
| Minimum Illumination | Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR on |
|||||||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||||||
| Digital noise reduction | 2D/3D DNR | |||||||||
| S/N | >56dB | |||||||||
| IR Range | Up to 50m (164ft) IR range | |||||||||
| Wavelength | 850nm | |||||||||
| IR On/Off Control | Auto/Manual | |||||||||
| Defog | Digital Defog | |||||||||
| WDR | 120dB | |||||||||
Video |
||||||||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||||||
| H.264 code profile | Baseline profile, Main profile, High profile | |||||||||
| Frame Rate | Main Stream: 4MP (2688*1520), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
|||||||||
| Video Bit Rate | 128 Kbps~16 Mbps | |||||||||
| 9:16 Corridor Mode | Supported | |||||||||
| OSD | Up to 4 OSDs | |||||||||
| Privacy Mask | Up to 4 areas | |||||||||
| ROI | Up to 8 areas | |||||||||
| Motion Detection | Up to 4 areas | |||||||||
Image |
||||||||||
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 | |||||||||
| Digital noise reduction | 2D/3D DNR | |||||||||
| Smart IR | Supported | |||||||||
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise | |||||||||
| Dewarping | N/A | |||||||||
| HLC | Supported | |||||||||
| BLC | Supported | |||||||||
Audio |
||||||||||
| Audio Compression | G.711 | |||||||||
| Suppression | Supported | |||||||||
| Sampling Rate | 8KHZ | |||||||||
Storage |
||||||||||
| Edge Storage | Micro SD, up to 256GB | |||||||||
| Network Storage | ANR,NAS(NFS) | |||||||||
Smart |
||||||||||
| Behavior Detection | Cross line, intrusion(based on human body detection) | |||||||||
| motion detection, tampering alarm, audio detection | ||||||||||
| General Function | Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication | |||||||||
Network |
||||||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS, 802.1x, SNMP | |||||||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | |||||||||
| Client | EZStation EZView EZLive | |||||||||
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below | |||||||||
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ | ||||||||||
Interface |
||||||||||
| Network | 10/100M Base-TX Ethernet | |||||||||
| Built-in Mic | Supported | |||||||||
Certifications |
||||||||||
| Certifications | UL: UL60950-1 FCC: FCC Part 15 | |||||||||
General |
||||||||||
| Power | DC 12V±25%, PoE (IEEE 802.3af) | |||||||||
| Power consumption: Max 8.5W | ||||||||||
| Dimensions (L × W × H) | 206 × 74 × 74mm (8.1” × 2.9” × 2.9”) | |||||||||
| Net Weight | 0.55kg (1.2lb) | |||||||||
| Material | metal | |||||||||
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||||
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | |||||||||
| Surge Protection | 6KV | |||||||||
| Ingress Protection | IP67 | |||||||||
| Reset Button | Supported | |||||||||
