Reolink 16CH NVR 4K 8MP PoE Human Car Detect Security System 5X Optical Zoom
Reolink 16CH NVR 4K 8MP PoE Human Car Detect Security System 5X Optical Zoom
SKU:RLK16-811B8-A
Smart 4K PoE
Camera System with 5X Optical Zoom & Spotlights
4K 8MP Ultra HD
Color Night Vision
Person/Vehicle Detection
16-Channel NVR
Smart Detection:
More Accurate Alerts
The security system can intelligently distinguish people, vehicles, and pets from other objects to offer more accurate detection, greatly reducing false alarms caused by the movements of trivial objects.
Double Warning for the Unwelcome
When an intruder is detected, the camera's spotlights and siren will be activated to alert you and deter the would-be criminal, effectively stopping crime before it happens. You can also manually turn the spotlights and siren on or off.
Two-Way Talk
The built-in mic and speaker allow you to hear and respond in real time to anyone on the other side of the camera - say hello to family and friends or warn off suspicious strangers.
Note: This function is only available in the Reolink App/Client.
Brighten the World with 4K UHD
This 8MP security system delivers excellent 4K videos, providing an even better viewing experience. You can easily view the richest and most minute details captured by the cameras.
Different Modes, Different Night
Worlds
In the absence of daylight, spotlights and infrared LEDs continue to bring you a bright image at night. You can easily switch between different night vision modes to watch clear and smooth videos in color or in black and white.
5X Optical Zoom for More Details
The camera's motorized varifocal lens offers a 31° - 105° * viewing angle and 5X optical zoom, allowing you to zoom in for a sharp closeup or zoom out for a clear overview.
Easy & Economical PoE Installation
Transmission of both power and data is handled by one single network cable for each Power-over-Ethernet camera in the RLK16-811B8-A kit. Less wiring, less cost, more convenience.
24/7 Continuous Recording
With a built-in 4TB hard drive (expandable up to 12TB), RLK16-811B8-A PoE camera system supports simultaneous recording and live streaming of up to 16 cameras. You will have all-day videos without missing a beat.
Work with Various Reolink IP Cameras
This 8MP 4K security camera system is expandable with up to
16 cameras—bullet, dome, or PTZ; 12MP, 8MP, 5MP, or 4MP. Reolink offers
multiple choices of security system customization to cover every corner of your
home, shop, or factory.
* Reolink cameras are recommended
for the best compatibility.
Be Robust, Rain or Shine
Withstanding harsh weathers is never difficult, thanks to the rugged and waterproof housing of the cameras. They do not fear heat, cold, or extreme weathers.
Specifications:
Hardware
V2
Video/Audio Input
IP Video Input
PoE IP camera x 16
Audio Input
Cameras with built-in mic
Video/Audio Output
Video Output
VGA, HDMI
Display Resolution
VGA: 1920*1080, 1280*1024, 1280*720, 1024*768
Audio output
1-channel, RCA
Decoding
Live View/Playback Resolution
4096*3072/3840*2160/2560*1920/2560*1440/2048*1536/2304*1296/1080p/720p
Video Format
H.265, H.264
Synchronous Playback
Up to 4 channels
HDD
SATA
2 x SATA interface (1 x 4TB HDD included)
Capacity
Up to 12TB (max. 6TB capacity for each HDD)
External HDD
No
External Interface
USB Interface
2 x USB 2.0
Network Interface
• 1, RJ-45 10/100 Mbps self-adaptive Ethernet interface for LAN/WAN
• 16, RJ-45 10/100 Mbps self-adaptive PoE Ethernet interface for IP camera
PoE
Max. Power Per Port
25W
Supported Standard
IEEE 802.3 af/at
Network
Network Protocol
HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS, DDNS, NTP, FTP
Browser Supported
Firefox, Chrome, Edge, Safari
OS Supported
PC: Windows, Mac OS; smartphone: iOS, Android
Max. User Access
20 users (1 admin account & 19 user accounts); up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
General
Power Supply
DC 48V~54V
Power Consumption
<10W (without HDD & PoE)
Working Environment
Temperature: -10°C~+45°C (14°F~113°F); humidity: 10%~90%
Dimensions
330 x 45 x 285mm
Weight
2.4kg
Video & Audio
Image Sensor
1/2.8" CMOS Sensor
Video Resolution
Default: 3840 x 2160 (8.0 megapixels) at 25 frames/sec
Lens
f=2.7-13.5mm F=1.6-3.3, with IR cut
Optical Zoom
5X
Video Format
H.265
Field of View
• Horizontal: 105°- 31°
• Vertical: 55°- 17°
Day & Night
Auto-switching with IR-cut filter
Infrared Night Vision
Up to 30 meters (IR LED: 4pcs/28mil/850nm)
Color Night Vision
Spotlight: 5pcs/4W/6500K/450 lumens
Audio
Two-way audio
Power
PoE
IEEE 802.3af, 48V active
DC Power
DC 12.0V⎓1A, <12W
Interface
Power
DC power port
System
Reset button
Ethernet
One 10M/100Mbps; RJ45
Storage
Micro SD card slot (Max. 256GB)
Audio
Built-in microphone and speaker
Software Features
Frame Rate
• Mainstream: 2fps - 25fps (default: 25fps)
• Substream: 4fps - 15fps (default: 10fps)
Code Rate
• Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps)
• Substream: 64Kbps - 512Kbps (default: 256Kbps)
Browsers Supported
Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS; Smartphone: iOS, Android
Smart Alarm
Motion detection; person detection; vehicle detection; pet detection
Record Mode
Motion recording (default); scheduled recording; 24/7 recording
Protocols & Standards
HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Max. User Access
20 users (1 admin account & 19 user accounts); up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
Work with
Google Assistant
Working Environment
Temperature
Operating temperature: -10°C~+55°C (14°F~131°F)
Humidity
Operating humidity: 10% ~ 90%
Waterproof
IP66
Size & Weight
Dimension
80 x 72 x 238mm
Weight
838g
