| Video |
|---|
| Imaging Device |
1/2.8" 2MP CMOS |
| Resolution |
1920x1080 |
| Max. Framerate |
30fps / 25fps(60Hz / 50Hz) |
| Min. Illumination |
Color : 0.11Lux(F1.6)(30IRE)
BW : 0Lux(IR LED on) |
| Video Out |
BNC(AHD / TVI / CVI / CVBS Selectable) |
| Video Transmission Distance |
500m(5C2V Coaxial Cable) |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
3.2~10mm(3.1x) manual varifocal |
| Max. Aperture Ratio |
F1.6 |
| Angular Field of View |
H: 110.2°(Wide) ~ 32°(Tele) / V: 55.4°(Wide) ~ 18°(Tele) / D: 128.4°(Wide) ~ 36.6°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Manual |
| Lens Type |
DC auto iris |
| Operational |
|---|
| Camera Title |
Displayed up to 15 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅣ |
| Defog |
Support |
| Motion Detection |
4ea |
| Privacy Masking |
8ea, rectangular zones |
| Gain Control |
Low / Middle / High / Very High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
1 ~ 1/12,000sec |
| Video Rotation |
H-Rev / V-Rev |
| Analytics |
Motion detection |
| Alarm I/O |
MD output 1ea |
| Alarm Triggers |
Analytics |
| Alarm Events |
Alarm output |
| IR Viewable Length |
30m(98.43ft) |
| Coaxial Protocol |
ACP(AHD Coax Protocol), TCP(TVI Coax Protocol), CCP(CVI Coax Protocol)
CVBS : Pelco-C(Coaxitron) |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-30°C ~ +55°C(+22°F ~ +131°F) / Less than 90% RH |
| Certification |
IP66, IK10 |
| Input Voltage |
24VAC, 12VDC |
| Power Consumption |
Max 6W |
| Mechanical |
|---|
| Color / Material |
Dark grey / Aluminum |
| Product Dimensions / Weight |
Ø78.0x259.8mm(3.07x10.23"), 914g(2.02 lb) |
