| Video |
|---|
| Imaging Device |
1/3" 4MP CMOS |
| Resolution |
2560x1440 |
| Max. Framerate |
30fps@4M(N), 25fps@4M(P) |
| Min. Illumination |
Color: 0.16Lux(F1.2, 1/30sec)
BW: 0.009Lux(F1.2, 1/30sec) |
| Video Out |
BNC(AHD), additional CVBS for installation |
| Video Transmission Distance |
500m(5C2V Coaxial Cable) |
| Lens |
|---|
| Focus Control |
Manual |
| Lens Type |
DC auto iris |
| Mount Type |
C mount, CS mount |
| Operational |
|---|
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
UserBLC, HLC, DWDR |
| Digital Noise Reduction |
2DDNR |
| Motion Detection |
4 zones |
| Privacy Masking |
2 zones |
| Gain Control |
Low / Middle / High / Very High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
1/30 ~ 1/12,000sec(N), 1/25~ 1/12,000sec(P) |
| Video Rotation |
H-Rev/V-Rev |
| Analytics |
Motion detection |
| Serial Interface |
RS-485(Samsung-T, Pelco-D/P) |
| Alarm I/O |
MD Output 1ea |
| Coaxial Protocol |
ACP(AHD Coax Protocol), CVBS: Pelco-C(Coaxitron) |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH |
| Input Voltage |
24VAC, 12VDC |
| Power Consumption |
Max 3.6W |
| Mechanical |
|---|
| Color / Material |
Black / Aluminum, Ivory / Plastic |
| Product Dimensions / Weight |
59.6(W)×68.4(H)×92.7(D)mm (2.35"×2.69"×3.65"), 186g(0.41 lb)
|
