| Video |
|---|
| Imaging Device |
1/2.8" 2MP CMOS |
| Resolution |
1920x1080 |
| Max. Framerate |
30fps / 25fps(60Hz / 50Hz) |
| Min. Illumination |
Color: 0.09Lux(F1.2, 1/30sec)
BW: 0.009Lux(F1.2, 1/30sec) |
| Video Out |
BNC(AHD / TVI / CVI / CVBS Selectable) |
| Video Transmission Distance |
500m(5C2V Coaxial Cable)
300m(5C2V Coaxial Cable) |
| Lens |
|---|
| Focus Control |
Manual |
| Lens Type |
DC auto iris |
| Mount Type |
C mount, CS mount |
| Operational |
|---|
| Camera Title |
Displayed up to 15 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅣ |
| Defog |
Support |
| Motion Detection |
4ea |
| Privacy Masking |
8ea, rectangular zones |
| Gain Control |
Low / Middle / High / Very High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
1 ~ 1/12,000sec |
| Video Rotation |
H-Rev / V-Rev |
| Analytics |
Motion detection |
| Serial Interface |
RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm I/O |
MD output 1ea, External D/N 1ea |
| Alarm Triggers |
Analytics |
| Alarm Events |
Alarm output |
| Coaxial Protocol |
ACP(AHD Coax Protocol), TCP(TVI Coax Protocol), CCP(CVI Coax Protocol)
CVBS: Pelco-C(Coaxitron) |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH |
| Input Voltage |
24VAC, 12VDC |
| Power Consumption |
Max 3.5W |
| Mechanical |
|---|
| Color / Material |
Black / Aluminum, Ivory / Plastic |
| Product Dimensions / Weight |
68.4(W)×59.6(H)×92.7(D)mm(2.69×2.35×3.65"), 186g(0.41 lb) |
